DL 2016

Pabla Product Name : DL 2016

Also known as (Similar Names) : DL2016 , DL 2016 , DL 20 16 , HN2016 , HN 2016 , HN 20 16 , DL202616 , DL 202616 , DL 20 26 16 , HN202616 , HN 202616 , HN 20 26 16

Type: Full Complement Open End

Pabla Part No. 29140

Dimension: 20 x 26 x 16

Inner Diameter (Fw) = 20 mm

Outer Diameter (D) = 26 mm

Length (C)=16 mm , Tolerance = +0.00 , -0.20 mm

Radius = 0.80 mm Min.

Number of rollers = 32 Nos.

Weight = 0.020 Kg

Life Cycle,Dynamic Load and Speed

Basic dynamic load rating (radial) = 18100 N

Basic static load rating (radial) = 36500 N

Fatigue limit load (radial) = 4750 N

( N = newton , 1 N = 1 Kg x 9.85 )

Life cycle = 1,00,000 Kilometers average

Limiting speed Approx = 10000 RPM ( Grease application)

Limiting speed Approx = 15000 RPM ( Oil application)

Operating temp.(Ideal) = - 50 Degree celsius , + 100 Degree celsius
