WC 14X18X13

Pabla Product Name : WC 141813

Also known as (Similar Names) : K 141813 , K141813 , K 14 18 13 , K 1413 , K1413 , K 14 13

Type: Cage Bearing

Pabla Part No. 27106

Dimension: 14 x 18 x 13

Inner Diameter (Fw) = 14 mm

Outer Diameter (Ew) = 18 mm

Length (Bc)=13 mm , Tolerance = +0.00 , -0.20 mm

Number of rollers = 13 Nos.

Weight = 0.0083 Kg

Life Cycle,Dynamic Load and Speed

Basic dynamic load rating (radial) = 8200 N

Basic static load rating (radial) = 10100 N

Fatigue limit load (radial) = 1320 N

( N = newton , 1 N = 1 Kg x 9.85 )

Life cycle = 1,00,000 Kilometers average

Limiting speed Approx = 19000 RPM ( Grease application)

Limiting speed Approx = 29000 RPM ( Oil application)

Operating temp.(Ideal) = - 50 Degree celsius , + 150 Degree celsius
